Product Parameters:

Dimension :12500x2500x1580mm

Main beam:material Q345B,”H” beam height:500mm ,top/middle /bottom;12/6/14 mm

Side beam :#16 channel steel

Loading capacity :45 T

Paint: Powder spraying and coating

Color:Per customer’s requirement

Axle:BPW/Fuwa/Starway/ 13 ton x 3

Tire:12R22.5x 12 + one spare tyre

Rim:900*22.5 *13

Suspension:Mechanical suspension or air suspension(brand optional)

Leaf spring:Leaf spring 10pcs*90*13mm or air bag

Landing gear:JOST or other brand two-speed, landing gear 28T

Electrical System:24V 7-way socket; front marker lamp: white; side marker lamp: white & red; rear lamp: red; turning signal lamp: amber; wiring: electric cable protected by PVC conduit on main frame

Braking System :Dual line pneumatic brake, SAE hose and connector,without ABS

Accessories:Toolbox*1; spare tire carrier*2  ,    12 pcs container twist locking

Features

Application Range: Starway flatbed trailers are designed for efficient container handling. We can customize the trailer to suit your needs,if container transport or internal port use.

Main Beam Structure: The main beams Starway flatbed semi trailer is made by Q345 or T700 steel, providing a sturdy and durable frame that can loads heavy goods , even in bad road conditions.

Axle Configuration: We can offer 2-6 axles according to the length and loading capacity requirements ,the loading capacity of axles have 13/16/20 ton optional

Suspension System:  we offer mechanical suspension or air suspension according your demand.

Container Twist Locks: 12 sets which can load 20x20ft or 40ft container

Application and after-sale services:

Starway vehicle company promise two-year warranty period, during this period, under normal use if there is damage, we will provide free new spare parts

Main beam : 2 year

Suspension : one year

Axles /Axle bearing : one year

Breaking system : one year

Landing gear /Kingpin:one year

Tyre : 6 month
